Search Results for: free wheel
standard
standard
Orangatang – Moose Knuckles Bushings
JUICIER BOUNCE, TIGHTER PACKAGE.
Crafted for quick turning response and smooth edge-to-edge transitions, Orangatang Knuckles are the ultimate high-energy bushing upgrade for carving, pumping, dancing, and freestyle longboarding.
Orange = Soft
Purple = Medium
What’s in the box? Pack contains two insert barrel bushings, two gumdrop bushings, two large cup washers, and two small cup washers.
LONGBOARD BUSHING SPECS
Diameter: 0.95” (24.1 mm)
Height (gumdrop): 0.64” (16.3 mm)
Height (inset barrel) 0.59” (15 mm) barrel + 0.075” (1.91 mm) insert = 0.665” (16.9 mm) total
Formula: Randy Thane
Durometers: soft (orange, 87a), medium (purple, 90a)
RECOMMENDED WEIGHT RANGES
Soft: 65-190+ lbs / 29-86+ kg
Medium: 130-230+ lbs / 59-104+ kg
RESPONSIVE DESIGN – Two unique shapes for highly responsive and customizable turning. Sized for compatibility with most trucks. The inner diameter features precise tolerances for a snugger fit around the kingpin. The insert barrel features a small “step” to fill the gap between the kingpin and the hole of the hanger, reducing play in the assembly for a more precise response. The gumdrop is a smooth and subtle blend between a barrel and the more traditional cone shape, providing enhanced agility. The rounded edge allows for ultra-smooth turn initiation and improved interface with the washers.
HIGHLY TUNABLE – In the standard configuration, the insert barrel is placed on the bottom and the gumdrop on the top (like a traditional barrel/cone setup). You can also set up your trucks with double insert barrels (the height of the insert is half the thickness of a Paris bushing seat) or double gumdrops. Replace the included cup washers with flat washers for a less restrictive, highly linear turning rate.
RANDY THANE – Knuckles are poured in our extremely high-rebound Randy Thane formula, ideal for responsive, energetic turning.
KNUCKLES VS. NIPPLES – While both Knuckles and Nipples use the same Randy urethane formula, the two bushings offer distinct performance characteristics. Nipples are a great choice for riders seeking maximum rebound for pumping and carving, lively yet supportive turning, and reduced wheelbite. The wide (1” diameter) double-barrel design offers a highly defined center point with immediate resistance to turn that increases progressively with lean angle.
In contrast, Knuckles are well suited for riders seeking quicker edge-to-edge response and deeper carving capabilities. The narrower diameter (0.95”) and combination of shapes provide a blend between a stable base (barrel) and a more free-turning top (gumdrop). The result is quicker and easier turn initiation with less resistance and a greater ultimate lean angle. Additionally, Knuckles are compatible with most longboard trucks (including Paris, Bear, Randal, Carver, Gullwing, Tracker, Caliber, Atlas, Bolzen, Aera, Rogue, PNL, Ronin, etc).
standard
Orangatang – Nipples Bushings
Extra lively and energetic, these double barrel Nipples will get you all hot and heavy.
Sold as a set of four (4), including four thin and strong flat washers. Nipples are NOT recommended for every truck on the market, but they do work well with Paris, Tracker Fastracks and Randals (among others).
Orange = 85a = Soft
Purple = 87a = Medium
Yellow = 89a = Hard
What’s in the box? Purchase price includes 4 nipples and 4 washers.
Intention
Designed to provide a lively and energetic ride, Nipples will revitalize any setup for carving, pumping, dancing, freestyle and freeride.
Formula
Nipples are poured in our extremely high rebound Randy Urethane formula. We stumbled on this urethane a few years ago while testing ultra high rebound formulas for wheels, but we found this urethane to actually be too high rebound for a wheel urethane. Perfect for a bushing.
Specs & Features
Outer diameter: 1 inch
Height (top/roadside): 0.56 inch
Height (bottom/boardside): 0.66 inch
The bottom bushing carries most of the rider’s weight, so it is compressed more than the top bushing. The top bushing engages mostly when the rider leans in one direction to turn. To account for this difference in loading, we made the bottom bushing slightly taller than the top. Both top and bottom barrels are beveled on one edge for a better fit with large cupped washers (such as the stock parts on Paris and Tracker Racetrack trucks). However, we recommend flat washers in general (see below).
The first round of Nipples are packaged in sets of four bushings (two bottom barrels and two top barrels) and include four flat washers.
Hardness
The first release of Nipples will feature three hardness ratings: soft, medium, and hard. These are roughly equivalent to ratings of 85a, 87a, and 89a on the Shore A durometer scale. The reason we’ve chosen to use a relative hardness scale for our bushings is that Nipples feel and respond differently than many equivalently rated bushings, due to their dimensions. The Nipples feature a slightly larger-than-average diameter that is intended to provide more leverage against the hanger and more meaty volume to compress in every turn. Combined with a double barrel configuration, this allows for a predictable initiation and very consistent resistance throughout the hanger’s travel, even in softer durometers.
Recommended weight ranges for lower speed (under 20 mph) riding are below. For faster riding, we recommend going harder.
Soft (orange): 80-180 lbs / 35-85 kg
Medium (purple): 160-230 lbs / 70-105 kg
Hard (yellow): 200-270 lbs / 90-125 kg
Washers
We tested many washer configurations while developing our bushings and ultimately found that flat washers on both sides provided the response we were looking for. We found, however, that most commercial flat washers we tested were lacking in one performance area or another. Some were made of soft materials that bent over time, and most did not have the kind of consistency in thickness from one washer to the next that we wanted (thicker washers not only modify the angle at which the hanger sits but also tend to result in excess compression and a deadened feeling). So we decided to develop our own flat washers.
Our washers feature a 1-inch outer diameter and are 0.055 inch thick. They are made of strong, medium-carbon steel that resists bending. The manufacturing tolerances are very tight, so dimensions are consistent between parts. The wide diameter and low thickness help support the entire bushing without degrading their performance or interfering with the truck’s geometry.
While the Nipples are packaged with our own flat washers, there are many other washer setups that can change the riding experience. For instance, large cupped washers can be used for a slightly more restrictive feel, while a flipped small cup washer on the top bushing will provide a slightly “looser” turning response.
Compatibility
Nipple bushings fit Paris, Tracker Fastrack, Gullwing Charger II, and old (pre-2010) Bear trucks. They are not compatible with new Bears, Gullwing Chargers, or Indys. Nipples work with Randal trucks, but they do not sit completely contained in the bushing seat. Since the Randal bushing seat is so low, however, it does not interfere with the performance of the bushings. They fit Caliber trucks, but the lean becomes very restricted past a certain point.
Many of our ambassadors have also run Nipples in various precision trucks (e.g. Aera and Omen) with good results.
This compatibility list is based on the trucks we use most. Nipples will fit in any truck that can accommodate a 1-inch diameter bushing with a height of 0.66 (bottom) and 0.56 (top) inch.
Future Directions
We look forward to exploring many variations in bushing design in the future including shapes, sizes, and formulas.
standard
Loaded Boards – Icarus – Deck
Loaded pioneered the flexible dropthru board with the Dervish in 2007 and the Tan Tien in 2010. We’ve returned to our carving roots using many of the things learned over the past few years from our freeride boards, downhill boards, and our snowboard (with design cues from bacon). Combining wheel flares, cork, a balanced flex pattern and novel manufacturing methods, the Icarus is a milestone in our exploration of the soulful carving experience.
LONGBOARD SPECS
Length: 38.4” (97.5 cm)
Width: 8.6” (22 cm)
Wheelbase: 28.25” (71.76 cm)
Weight
Deck: 2.9 lbs (1.3 kg)
Complete: 6.5 lbs (2.9 kg) w/Fat Frees, 7.4 lbs (3.4 kg) w/Kegels
FLEX
Flex 1: 170-250+lbs / 75-115+kg
Flex 2: 75-200+lbs / 35-90+kg
Powerful Flex—Vertically laminated bamboo and fiberglass construction pair with a cambered profile and a variable concave for a lively and engaging ride. The cork bottom helps dampen out vibrations without compromising the liveliness.
User Friendly—Drop-through truck mounting positions the deck lower to the ground for easier, more efficient pushing and enhanced stability. Light weight and compact size make the Icarus intuitive and commuter friendly.
Shapely Curves—The right curves in the right places enhance rider ergonomics while contributing to a responsive and high-performance ride. Wheel well flares accommodate big wheels and improve turning leverage and control. Variable concave yields a consistent flex pattern while providing a variety of riding experiences based on foot placement.
Practical Kicks—Minimal nose and tail kicks help navigate city streets and open the door for freestyle trickery.
The Icarus: Because sometimes you need to fly too high.
SHAPE
The shape of the Icarus echoes the elegantly utilitarian outline popularized by the Dervish and Tan Tien. Its mid-sized length and wheelbase strike a balance between stability and maneuverability, accommodating a (slightly-wider-than-) shoulder-width stance for most riders. Straight rails along the standing platform ensure torsional stability, while full-figured cutouts at the tips allow for deep turns without wheelbite.
CAMBER
The cambered profile pairs with the bamboo core and epoxy/fiberglass skins (as well as the concaves and wheel flares) to create an active suspension with ungodly energy return. Pump away!
WHEEL WELL FLARES
Flared wheel wells do three things for the Icarus:
• Increase wheel clearance, allowing for larger wheels
• Stiffen the necks, creating more direct energy transfer to the trucks
• Create an ergonomic lock, letting you know where you are by feel and giving you strong leverage points to push against
VARIABLE CONCAVE
Because the flares stiffen the necks we needed to create a variable concave to balance out the flex pattern. Tighter concave in the center of the board prevents the deck from folding at the center, while more subtle concave underfoot near the flares locks you in and feels yummy. This was inspired by the flex patterning explored for our snowboard, the Algernon.
NOSE & TAIL KICKS
Minimal nose and tail kicks allow for enhanced maneuverability in tight quarters while also opening the door to exploring freestyle trickery. The kicks are reinforced with an additional layer of fiberglass for added stiffness and durability.
FLEX RECOMMENDATIONS
Flex 1: 170-250+lbs / 75-115+kg
Flex 2: 75-200+lbs / 35-90+kg
A softer flex gives you more control and tighter turns at slower speeds and makes it easier to slide, but it tends to lose stability slightly at higher speeds. Stiffer flex means more energy potential, more stability at higher speeds, and greater durability under hard freestyle riding, but it will not be as forgiving and lively when cruising. As always, our flex ratings are recommendations. Try ‘em out and see what suits you.
NAME & GRAPHICS
Drawing from Greek Mythology, this board takes its name from Icarus, whose master-craftsman father Daedalus built the Labyrinth for King Minos to imprison the Minotaur. After Daedalus himself was imprisoned by Minos, he created two pairs of wax and feather wings for himself and Icarus to use in escaping the island of Crete. Despite his father’s warning to follow his flight path, Icarus found himself captivated by the thrill of flight and ascended too high into the sky. The sun’s heat melted the wax in his wings, causing him to fall into the sea.
Moral of the story? Get better wings.
CONSTRUCTION
Epoxy and triaxial fiberglass sandwich a 5-part vertically laminated bamboo core, pressed into concave and convex cambers for liveliness, responsiveness and high energy potential. Drop-through cutouts are CNC milled for precision.
Biscuits and Gravy: To achieve the dramatic wheel well contours without cracking the core, we developed “biscuit” inserts. We machine out the cores in areas of extreme curvature (where the wild wheel flares are) and drop in four separate bamboo “biscuits” in order to mitigate the stresses. The “five” resulting cores are bonded together using our proprietary, high performance epoxy and sandwiched between triaxial glass skins to create this curvaceous beast.
An extra layer of fiberglass is applied on the nose and tail for additional rigidity in the kicks.
standard
Loaded Boards – Bhangra – Deck
The Loaded Boards Bhangra is built with a dancer in mind. If you’ve ever had a chance to see Adam Colton ride this boat of a board you’ll understand just how fun it can be.
A more compact dancing/freestyle deck, the Bhangra offers plenty of foot space to get your dancing groove on yet is compact and lightweight enough to facilitate steezy slides and advanced flatland tricks. Upturned nose and tail kicks, purposeful griptape patterns, rocker, mellow concave and damp flex (created in part by the use of epoxy bio-resin & cork) result in comfortable and functional ergonomics that inspire confidence on both the dance floor and the hills.
Length: 48.5″ / 123 cm
Width: 9.5″ / 24 cm
Wheelbase (Inner Hole): 32.75″ / 83.19 cm
Weight:
Deck: 5.6 – 6.3 lbs / 2.5 – 2.9 kg
Complete: 9.4 – 10.1 lbs / 4.3 – 4.58 kg
FLEX
Flex 1 150-270+ lbs / 75-122+ kg
Flex 2: 90-190+ lbs / 40-86+ kg
ROCKER
The rocker (slight “U” bend when viewed from the side) really sinks you into the board and gives you that extra cushy, locked in feel. Feels great for dancing, makes sliding a lot easier and more comfortable, and puts the board lower to the ground, making pushing slightly easier.
CONCAVE
We added a mellow “U” concave to give you more confidence when sliding. The concave also helps lock your feet in when landing big spins and such but is still mellow and comfortable enough for footwork moves.
NOSE AND TAIL KICKS
More nose and tail curvatures allow for easier catching of the nose and tail. With good timing, you can ollie the Bhangra. Not easy, but it can be done. Both the nose and tail will lock your feet in nicely for manuals, but the different lengths result in distinct feelings of balance and pop. You may find riding the board in a certain direction better for some tricks; for example, the tail is really good for catching shuvits-to-manuals, while the nose feels better for hang ten manuals.
GRIPTAPE
This is our most thought out grip design to date featuring a functional, shoe saving design and two different types of griptape.
For the main standing platform, we used a mellower grip with a functional pattern to save your shoes. As you all know, when you do pivot motions on grip tape you slowly wear out the balls of your shoes; you are basically grinding away your soles on sandpaper. We cut out this grip design so that when you do your spinning moves, most of your shoe will move freely on the bamboo, not the grip tape. We also designed it so you still have plenty of grip tape on the rails of the board for confidence when sliding.
We used a gnarlier, gripper griptape on the nose and tail to help give you that extra locked in feeling when holding out manuals. The extra grip also makes it easier to catch the nose and tail for quick shuvit-to-manual moves.
EPOXY BIO-RESIN
Resin plays a big part in how a board feels. We tried out a variety of resins, each having their own energy return properties and flex characteristics. For a board like this, we really dug a more mellow, damp feeling resin. Something that sinks nicely under your feet and does not have so much energy return that it wants to buck you off. We classify the flex as soft, damp, almost “dead” flex. In contrast, a Dervish Sama has a more lively, springy flex.
WHEEL WELLS
We designed functional wheel wells to accommodate several brands of 180mm trucks and 70mm wheels without risers. They will prevent wheelbite in most circumstances; however, you may encounter bite if you run super loose trucks with soft bushings.
FLEX
Flex 1: 150-250+ lbs
Flex 2: 90-190+ lbs
Flex 2 is what Adam S. (150 lbs) and Adam C. (160 lbs) ride. The Adams prefer a board with a bit of flex to it (feels a lot better for freestyle). You can still take the flex 2 plenty fast and do slides comfortably, thanks to the rocker and concave. Flex 1 is definitely stiffer, and if you are 160 lbs it will flex only slightly under you. If you like stiffer boards and plan on doing hard pounding tricks with this board or weigh more (over 190 lbs), this is your board.
DIRECTIONAL SHAPE
Distinct nose and tail shapes create different amounts of leverage for different tricks. The standing platform is slightly wider in the front of the board to concentrate leverage over the front truck for predictable turn initiation while dancing.
standard
#FlatspotDeckOfTheDay: Comet Ethos 40″
Grab some epically janky trucks, stick em on one of these radtastic Comet Ethos 40″s and slappy a curb and bomb a hill on in the same run. Its made for all the things and nothing less.
standard
Landyachtz Dinghy – BIG Fun Small Boards
Size isn’t always a determining factor when it comes to good times and the Landyachtz Dinghy is certainly no stranger to fun.
standard
#FlatspotDeckOfTheDay – Longboard Larry Hippo
An exceptionally versatile board with molars to match!
standard
standard
Loaded – Overland – Complete
Loaded – Overland complete with Polar Bear 155mm trucks, 80a Fat Frees and Zealous bearings.
Length: 37” (94cm)
Width: 9.5” (24cm)
Wheelbase: 20.75” and 22” (52.71 and 56 cm)
Rocker: 0.125″ / 0.318 cm
Concave: 0.50″ / 1.3 cm
Nose angle: 18°
Tail Angle: 13°
Nose: 4.9″ / 12 cm from outermost bolt
Tail: 5.9″ / 15 cm from outermost bolt
